HOME DELIVERY W/LIFTGATE SERVICE
- Rack & Pinion Steering
- PROTECTIVE UTILITY SIDE GUARDS NETTING
- Mechanical Rear Dump Bed = No Muscle Strain!
- Full Parts and Warranty Support Included!
- Fully Automatic chain driven Transmission /Foward/Reverse
- Front Headlights/ Low & High Beam Led Lights
- Rear Brake lights+Left Right Signal Lights
- Front Suspension / Adjustible Double A-arm
- Rear Suspension Dual shock Swing arm
- Front/Rear Hydraulic Disc-Brakes
- Single Cylinder with Oversized Pistons
- Rear Brake and Reverse Lights
SPECIFICATIONS
- Certification EPA approved
- Engine type 4-stroke,Single-Cylinder, Air/Oil-cooled
- Displacement 149.6cc
- Horse Power 7.45kw(7000r/min) 10HP
- Valve Configuration OHV
- Compression ratio 9.0:1
- FUEL SYSTEM
- Fuel Delivery System Fuel Pump Carburetor
- Choke System Automatic
- Fuel capacity 9.5L (2.1 Gallon)
- DRIVETRAIN
- Driveline Type 2X4
- Final Drive Chain-drive
- Transmission Constantly Variable Transmission
- Gear Selection Forward & Reverse Single Speed
- ELECTRICAL SYSTEM
- Forward Lights Headlights-High & Low Beam LED LIGHT
- Rear Lights Brake Lights & Left/Right Signal lights
- Starting system Electric start
- Ignition system C.D.I
- SUSPENSION / BRAKES
- Suspension Front Adjustable Double A-arm optional
- Suspension Rear Dual Shock Swing arm
- Brakes Front Front Dual Hydraulic Disk
- Brakes Rear Rear Single Axle Hydraulic Disk
- Steering Rock and pinion steering
- TIRES
- Front Tread 1020mm ( 40.2 in)
- Rear Tread 1040mm ( 38.0in)
- Front & Rear tire size 22x8-10 / 22x10-10
- MISC
- Loading information 8 units/20″; 26units/40HQ
- Top speed 55km/h
- Dry weight 245kg ( 540 lbs.)
- Gross weight 280kgs(617lbs)
- Wheelbase 1860mm (71.0in)
- Vehicle dimension (L×W×H) 2450x1220x1397mm ( 96.5x 48.0x55.0 in)
- Packing size 2290x1300x815mm
- Ground clearance 152mm (6in)
- Safety Driver & Passenger Seat belts/ Driver and Passenger safety net restraints.
BE A RESPONSIBLE RIDER! FOR SAFETY, READ YOUR OWNER'S MANUAL. ALWAYS WEAR A HELMET, EYE PROTECTION, AND PROTECTIVE CLOTHING! NEVER RIDE UNDER THE INFLUENCE OF DRUGS OR ALCOHOL! Parents consider your youngsters age, size, ability, and maturity before allowing them to ride. Never ride on paved streets or public roads, and never carry passengers on your ATV. Never engage in stunt driving or ride at excessive speeds. Be careful on difficult terrain. Riders under 16 years of age must be supervised by an adult. Countyimports.com recommends that ALL riders take a training course. For more information visit the ASI website www.safety.org.
- Free Technical Support 1-877-300-8707 on all products purchased from our website
- Parts ship same day in most cases
- Unit must be assembled - please read the purchaser responsibility below
Please remember that by purchasing an ATV online, you are responsible for performing the setup that a dealer would normally perform - such as putting on tires, hooking up the battery, checking tightness of all nuts and bolts, changing oil, etc.
