| SPEC |
STATUS |
| Engine Mode |
ZONGSHEN -ZS154FMI-2 |
| Engine Type |
SINGLE CYLINDER,AIR COOLER |
| Displacement(ml) |
124 |
| Max.Power(kw/r/min) |
6.3(1±10%)/7500(1±5%) |
Max.Torque (N.m/r/min) |
8.8(1±10%)/5500(1±5%) |
| Compression Ratio |
9.0：1 |
Bore and Stroke(mm×mm) |
54×54 |
| Ignition method |
CDI |
| Lubrication method |
Pressure spray |
| 润滑油牌号 |
10W/40 |
| Starting method |
KICK START |
| Clutch method |
Manual wet multi piece type |
Gearshift Method |
Normally engaged two-stage transmission with four gears |
| transmission |
Chain |
| spark |
A7TC |
| size ： |
1820*750*1130 |
| mm wheelbase |
1250 |
| mm seat height |
850 |
| mm ground clearance |
280 |
| top rake |
21 |
| mm Minimum turning radius |
2300 |
| gear ratio |
428H/14:41 |
| break |
fr. & re.: disc fr: φ210; re:φ190 |
| break type |
front hand break, rear foot break |
| wheel |
steel wheel, 1.6*17 & 1.85*14 |
| tyre |
fr：70/100-17 re：90/100-14 |
| Fr. suspension |
up side downφ45×φ48×735 |
| Re. suspension |
φ12×350 |
| mm foot pedal to seat |
530 |
| carb |
PE19 |
| L tank capacity |
4 |
| muffler |
aluminum muffler |
| frame |
φ35 material |
| rear swing arm |
Sheet metal forming in one |
| kg Max load |
100 |
| kg NW |
75 |
| kg Gw |
95 |
| packing way |
take off fr. suspension, packed by steel frame and carton |
| packing size |
1400*650*380 |
